4.2 Coordinate systems

Basic logic functions: Axes, coordinate systems, frames (K2)

Function Manual, 11/2006, 6FC5397-0BP10-2BA0

145

Part program in first channel

Code (excerpt) Comment

. . .

N100 $P_NCBFR[0] = CTRANS( x, 10 )

; Activation of the NC global basic frame

. . .

N130 $P_NCBFRAME[0] = CROT(X, 45)

; Activation of the NC global basic frame with rotation =>

alarm 18310, since rotations of NC global frames

are not permitted

. . .

Part program in second channel

Code (excerpt) Comment

. . .

N100 $P_NCBFR[0] = CTRANS( x, 10 )

; The NCU global basic frame is also active in second channel.

. . .

N510 G500 X10

; Activate basic frame

N520 $P_CHBFRAME[0] = CTRANS( x, 10 )

; Current frame of second channel is activated with an offset.

. . .

Function Manual - Basic Functions1
