Siemens SINUMERIK 840C Installation Guide

09.01 1 NC/Drive Machine Data
1.1 General values
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
157 Control type for
standard cycles
T 61..
M 62..
--
--
-- --
160 Interpolation cycle 4 32 -- --
161 Number of IKA configurations via
PLC/DB 48
032----
164 Deadtime for calculation for
extended thread
36
28
4)
48 --
1
/
8
of IPO clock
frequency
168 Basic cycle time for drive 16 32 -- 62.5 µs
200 Reserved
208 Maximum tool wear P5, P6 999 999 999 999
99 999 999
3)
-- 0.01 units
0.00001
209 Maximum tool wear P7 999 999 999 999
99 999 999
3)
-- 0.01 units
0.00001
210 Number of TO areas 1 4 -- --
211 Start D No. for TO area 1 1 809 -- --
212 ” ” 2 0 809 -- --
213 ” ” 3 0 809 -- --
214 ” ” 4 0 809 -- --
228 User menu for MDA 0 1000 -- --
229 User menu for JOG 0 1000 -- --
230 User menu for TEACH IN 0 1000 -- --
231 User menu for AUTOMATIC 0 1000 -- --
232 User menu for JOG/REFPOINT 0 1000 -- --
250 Change of language
1)
0 1 -- --
260 M function ”C axis ON”
- 1 9999 -- --
261 M function ”C axis OFF”
- 1 9999 -- --
300 Tool allowance for protection
zone adjustment
0 9999 9999 IS --
310
2)
Output byte to user interface 0 94
999
3)
-- --
311
2)
Output byte to mixed I/O 0 22
999
3)
-- --
312 Assignment of outputs
module
2)
for emergency
retraction 1st mode grp
022
2
2)
-- --
313
:
Assignment of outputs
module
2)
for emergency
retraction 2nd mode grp
022----
317 Assignment of outputs
module
2)
for emergency
retraction 6th mode grp
MDs 314 to 317 (as from SW 4)
022
2
2)
-- --
_______
1)
Up to SW 1
2)
SW 3 and higher
3)
SW 4 and higher
4)
SW 5 and higher
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60
1–5
SINUMERIK 840C (IA)
