Siemens SINUMERIK 840C Installation Guide

1 NC/Drive Machine Data 01.99
1.1 General values
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
318
:
323
Assignment of inputs of Mixed
I/O module for retraction of one
mode group 1st mode group
:
6th mode group
1)
081
8
1)
-- --
324 Time for interpolator-controlled
continuation
1)
0 1 000
16 000
1)
-- ms
325 Maximum time for interpolator-
controlled deceleration
1)
0 1 000
16 000
1)
-- ms
330 Deadtime compensation for
dwell axis actual value
1)
550 16 000 -- % of IPO
cycle
331 Sine of angular range for
tangential transitions TRC
2
ˆ=approx.
0.0005 deg.
16 000
ˆ=approx.
4.5 degrees
-- 0.5 * 10
-5
332 Deadtime compensation dwell
axis setpoint
2)
450 16 000 -- % of IPO
cycle
333 Deadtime compensation dwell
spindle actual value
2)
550 16 000 -- % of IPO
cycle
334 Deadtime compensation dwell
spindle setpoint
2)
450 16 000 -- % of IPO
cycle
335 Min. reduction factor
(velocity limitation FA warning
threshold)
3)
100 100 -- %
336 Velocity increase factor
(velocity linitation FA warning
threshold)
3)
0 1000 -- 0.01 %
337 2nd MCS displacement in X
coordinates
3)
0 9999 9999 IS units
338 2nd MCS displacement in Y
coordinates
3)
550 16 000 IS units
339 2nd MCS displacement in Z
coordinates
3)
550 16 000 IS units
340 3rd MCS displacement in X
coordinates
3)
550 16 000 IS units
341 3rd MCS displacement in Y
coordinates
3)
550 16 000 IS units
342 3rd MCS displacement in Z
coordinates
3)
550 16 000 IS units
343 4th MCS displacement in X
coordinates
3)
550 16 000 IS units
344 4th MCS displacement in Y
coordinates
3)
550 16 000 IS units
345 4th MCS displacement in Z
coordinates
3)
550 16 000 IS units
_______
1) As fromSW 4
2) As from SW 5
3) As from SW 6
1–6 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
