01.99 1 NC/Drive Machine Data
1.1 General values
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
730 Delta X offset 0 ±99999999 IS units
731 Delta Y offset 0 ±99999999 IS units
732 Delta Z offset 0 ±99999999 IS units
733 Angle of rotation X 0 ±99999999 IS 10
-5
734 Angle of rotation Y 0 ±99999999 IS 10
-5
735 Angle of rotation Z 0 ±99999999 IS 10
-5
736 Parameter 7 0 ±99999999 IS units
737 Parameter 8 0 ±99999999 IS units
738 Minimum speed for TRANSMIT 10 ±99999999 IS units/IPO cycle
739 Axis with constant cutting
speed
0 30 Number of the
axis for G96
740 2nd transformation, param. 1 0 ±99999999 IS units
. - // -- // -- // -- // -- // -
750 3rd transformation, param. 1 0 ±99999999 IS units
. - // -- // -- // -- // -- // -
760 4th transformation, param. 1 0 ±99999999 IS units
. - // -- // -- // -- // -- // -
770 5th transformation, param. 1 0 ±99999999 IS units
. - // -- // -- // -- // -- // -
780 6th transformation, param. 1 0 ±99999999 IS units
. - // -- // -- // -- // -- // -
790 7th transformation, param. 1 0 ±99999999 IS units
. - // -- // -- // -- // -- // -
800 8th transformation, param. 1 0 ±99999999 IS units
. - // -- // -- // -- // -- // -
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–7
SINUMERIK 840C (IA)
