Siemens SINUMERIK 840D sl Operating Instructions

Requirements for operation
1.2 Legal framework
eP-Satellite server
12 Operating Instructions, 06/2009
Server Function Minimum requirements
eP-Satellite application
reporting database
server
(optional)
Saving and managing
information relating to
reporting
MS Windows Server 2003 Enterprise Edition,
English
MS SQL Server 2005 Enterprise Edition,
English, incl. SP2
.NET Framework 2.0, English
eP-Satellite application
reporting web server
(optional)
Preparing and displaying
reporting information
with the aid of reports
MS Windows Server 2003 Enterprise Edition,
English
MS IIS 6.0 (part of the OS)
MS SQL Server 2005 Reporting Services (web
services) incl. SP2
.NET Framework 2.0, English
.NET Framework 3.0, English
.NET Framework 3.5, English
Note
The instructions that follow assume that all server systems are members of an active
directory domain.
In order to unzip each of the installation packages, a data compression program that
supports both .zip and .cab archives must be installed on all of the servers.
When calculating the size of the database, the following event sizes apply:
Event Size in KB
(estimation)
TE Trigger event (size dependent on optional file upload) 470
EH Event history entry 70
SC Service case (fault message) 65
AC Archive components (PLC archive, NC archive) 645
UAT Universal axis test 1.085
GLT Equability axis test 350
KFT Circularity test 450
MT Maintenance ticket 320
MTT Maintenance ticket template 350
Alarm model, 5 to 7 MB 6.000

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
