Siemens SINUMERIK 840D sl Operating Instructions

Requirements for operation
2.1 Basic configuration: Server systems
eP-Satellite server
Operating Instructions, 06/2009
15
Configuring the SQL Server following installation
Cross Database Ownership In the SQL Server Management Studio,
right-click the database instance, select
"Properties", and activate the "Cross
database ownership chaining" option
under the "Security" menu command.
Remote Connections In the SQL Server Management Studio,
right-click the database instance, select
"Properties", and activate the "Allow
remote connections to this server"
option under the "Connections" menu
command.
Note
The eP-Satellite system consists of a total of six databases which - in general - can only be
saved at different times. To be able to restore all databases to the same level, it is necessary
that a "Point in Time Restore" can be executed. A prerequisite for this are transaction logs.
These should, therefore, also be saved separately.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
