Requirements for operation
2.7 Implementation example: IT infrastructure
eP-Satellite server
30 Operating Instructions, 06/2009
K4
Communications between:
Protocol:
Type:
Purpose:
Specification:
ePS Network Services client (type 1) and eP-Satellite server
HTTPS, SOAP
Permanent
Using ePS Network Services
WSDL 4
K5
Communications between:
Protocol:
Type:
Purpose:
Specification:
ePS Network Services client (type 2) and eP-Satellite server
HTTPS, SOAP
Permanent
Using ePS Network Services
WSDL 5
K6, K7
Communications between:
Protocol:
Type:
Purpose:
Specification:
eP-Satellite application server and DC portal server
HTTPS, SOAP
Permanent
Making ePS Reports available
WSDL 6, 7
K8
Communications between:
Protocol:
Type:
Purpose:
Specification:
eP-Satellite external web server and
eP-Satellite database server
TCP, ADO.NET
Permanent
Using ePS Network Services for the support
---
Figure 2-1 Example: IT infrastructure

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
