Siemens SINUMERIK 840D sl Operating Instructions

Release management - ePS Reporting Services
4.2 Configuring Microsoft Reporting Services
eP-Satellite server
72 Operating Instructions, 06/2009
The image below shows the completed settings:
Figure 4-3 Login
Changing the credentials for connection
Relevant servers eP-Satellite application reporting web server
Change the values for the user you have just created under "Database Connection" to the
following:
Credentials Type SQL Server Credentials
Account Name ePSRepSQLServiceUser
Password %ePSRepSQLServiceUserPassword%
Domain account
Reporting Web Services is normally configured in IIS using "Windows Authentication". Since
the eP-Satellite runs as a web application in IIS under user "Anonymous", the SQL Server
Reporting Web Services component used for redirection must also run under "Anonymous".
For this purpose, a domain account that is entered as "Anonymous" for the Report Viewer
must be created. In the SQL Server, this user must be assigned the role "RSExecRole" for
both the report server and the ReportServer TempDB database.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
