© Siemens AG All rights reserved. SINUMERIK, Manual, 5-axis machining
Reference section
7.1
105
Tool radius compensation
2½D circumferential milling
3D circumferential milling
Face milling
3D circumferential milling with limitation surface - Combined circumferential/face milling
G40
G41
G42
G450
G451
Deactivation of all variants
Activation for circumferential milling, compensation direction left
Activation for circumferential milling, compensation direction right
Circles at external corners (all compensation types)
Intersection method at external corners (all compensation types)
CUT2D
CUT2DF
2 1/2D COMPENSATION with compensation plane determined
using G17 - G19
2 1/2D COMPENSATION with compensation plane determined
using a frame
CUT3DC Compensation perpendicular to path tangent and tool orientation
ORID No changes in orientation in inserted circular blocks at external
corners. Orientation motion is performed in the linear blocks.
ORIC Travel path is extended by means of circles. The change in orien-
tation is also performed proportionately in the circle.
CUT3DFS Constant orientation (3-axis). Tool points in the Z direction of the
coordinate system defined via G17 - G19. Frames do not have
any effect.
CUT3DFF Constant orientation (3-axis), tool in Z direction of the coordinate
system currently defined via the frame.
CUT3DF 5-axis with variable tool orientation
CUT3DCC NC program relates to the contour on the machining surface.
CUT3DCCD The NC program relates to the tool center point path.
