General information on workpiece production

2.5

Requirements for using cycles

 The measuring cycles must have been installed

 The workpiece must have been clamped

 The probe must have been calibrated and must be active; the tool offset must have been acti-

vated

Examples of measuring cycles

Align plane

The Tool and Mold Making (3 axes) manual contains detailed examples of how to set up

machines with two rotary axes.

Align plane (CYCLE998)

The plane's position within the machine coor-

dinate system is determined using 3-point

measurement. If the Swivel/5-axis transforma-

tion option has been set up, the table/head will

be aligned in accordance with the compensa-

tion values when the WO is determined.

NOTE
