6. Insert the booster â‘­ via the threaded bolts â‘¢.




7. Fasten the booster ⑭ with the lock washers ④ and nuts ⑤. When tightening, make sure
that the shaft â‘  can be turned easily.




Booster
E.2 Mounting a booster
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 303
