A Appendix
642
7SD5 Manual
C53000-G1176-C169-1
274 Set Point Phase L2 dmd> (SP.
IL2 dmd>)
Set Points(MV) OUT on
off
**LEDBO
275 Set Point Phase L3 dmd> (SP.
IL3 dmd>)
Set Points(MV) OUT on
off
**LEDBO
276 Set Point positive sequence
I1dmd> (SP. I1dmd>)
Set Points(MV) OUT on
off
**LEDBO
277 Set Point |Pdmd|> (SP. |Pdmd|>) Set Points(MV) OUT on
off
**LEDBO
278 Set Point |Qdmd|> (SP. |Qdmd|>) Set Points(MV) OUT on
off
**LEDBO
279 Set Point |Sdmd|> (SP. |Sdmd|>) Set Points(MV) OUT on
off
**LEDBO
285 Power factor alarm (cosϕ alarm) Set Points(MV) OUT on
off
**LEDBO
289 Alarm: Current summation super-
vision (Failure Σi)
Measurem.Superv OUT ON
OFF
* * LED BO 135 250 1 Yes
290 Alarm: Broken current-wire de-
tected L1 (Broken Iwire L1)
Measurem.Superv OUT ON * * LED BO 135 137 1 Yes
291 Alarm: Broken current-wire de-
tected L2 (Broken Iwire L2)
Measurem.Superv OUT ON * * LED BO 135 138 1 Yes
292 Alarm: Broken current-wire de-
tected L3 (Broken Iwire L3)
Measurem.Superv OUT ON * * LED BO 135 139 1 Yes
295 Broken wire supervision is
switched OFF (Broken wire OFF)
Measurem.Superv OUT ON
OFF
**LEDBO
296 Current summation superv is
switched OFF (Σi superv. OFF)
Measurem.Superv OUT ON
OFF
**LEDBO
301 Power System fault
(Pow.Sys.Flt.)
P.System Data 2 VI ON
OFF
ON * 135 231 2 Yes
302 Fault Event (Fault Event) P.System Data 2 VI * ON * 135 232 2 No
303 E/Flt.det. in isol/comp.netw. (E/F
Det.)
P.System Data 2 VI ON
OFF
*ON*
351 >Circuit breaker aux. contact:
Pole L1 (>CB Aux. L1)
P.System Data 2 SP * * * LED BI BO 150 1 1 Yes
352 >Circuit breaker aux. contact:
Pole L2 (>CB Aux. L2)
P.System Data 2 SP * * * LED BI BO 150 2 1 Yes
353 >Circuit breaker aux. contact:
Pole L3 (>CB Aux. L3)
P.System Data 2 SP * * * LED BI BO 150 3 1 Yes
356 >Manual close signal (>Manual
Close)
P.System Data 2 SP * * * LED BI BO 150 6 1 Yes
357 >Block all close commands from
external (>CloseCmd.Blo)
P.System Data 2 SP ON
OFF
**LEDBIBO15071Yes
361 >Failure: Feeder VT (MCB
tripped) (>FAIL:Feeder VT)
P.System Data 2 SP ON
OFF
* * LED BI BO 192 38 1 Yes
362 >Failure: Busbar VT (MCB
tripped) (>FAIL:Bus VT)
P.System Data 2 SP ON
OFF
* * LED BI BO 150 12 1 Yes
366 >CB1 Pole L1 (for AR,CB-Test)
(>CB1 Pole L1)
P.System Data 2 SP * * * LED BI BO 150 66 1 Yes
367 >CB1 Pole L2 (for AR,CB-Test)
(>CB1 Pole L2)
P.System Data 2 SP * * * LED BI BO 150 67 1 Yes
368 >CB1 Pole L3 (for AR,CB-Test)
(>CB1 Pole L3)
P.System Data 2 SP * * * LED BI BO 150 68 1 Yes
371 >CB1 READY (for AR,CB-Test)
(>CB1 Ready)
P.System Data 2 SP * * * LED BI BO 150 71 1 Yes
378 >CB faulty (>CB faulty) P.System Data 2 SP * * * LED BI BO
379 >CB aux. contact 3pole Closed
(>CB 3p Closed)
P.System Data 2 SP * * * LED BI BO 150 78 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
