5.17.2 Setting Notes
T-Annunc.1
T-Annunc.2
T-Annunc.3
T-Annunc.4
The parameters T-Annunc.1 (2801/BU), T-Annunc.2 (2802/BU),
T-Annunc.3 (2803/BU) and T-Annunc.4 (2804/BU) are used to set the delay
times for the user-defined annunciations 1, 2, 3 and 4.
ANN1Inp.No
ANN2Inp.No
ANN3Inp.No
ANN4Inp.No
Use parameters ANN1Inp.No to ANN4Inp.No (2831/BU, 2832/BU, 2833/BU,
2834/BU) to set any annunciation numbers (see Appendix A.10, page 383) that can
be transferred to the central unit.
ANN1Fct.No
ANN2Fct.No
ANN3Fct.No
ANN4Fct.No
Use parameters ANN1Fct.No (2821/BU), ANN2Fct.No (2822/BU),
ANN3Fct.No (2823/BU) and ANN4Fct.No (2824/BU) to enter the annunciation
number of the binary input annunciation to be generated.
