Marshalling - Bay Unit 7SS525
401
7SS52 V4 Manual
C53000-G1176-C182-3
A.17 Marshalling - Bay Unit 7SS525
When the device is delivered, annunciations are marshalled to the binary inputs, re-
lays, and LEDs for the maximum scope. The functional keys are pre-assigned. The
marshalling can be found in Table A-31, page 401 to Table A-33, page 402.
Table A-31 Marshalling of the binary inputs of the bay unit 7SS525
Address 1st display line 2nd display line FNo. Comment
6101 BINARY INPUT1 >Isolator1on NO 7601 >Isolator 1 - position closed
6102 BINARY INPUT 2 >Isolator1off NO 7602 >Isolator 1 - position open
6103 BINARY INPUT 3 >Isolator2on NO 7603 >Isolator 2 - position closed
6104 BINARY INPUT 4 >Isolator2off NO 7604 >Isolator 2 - position open
6105 BINARY INPUT 5 >CB ON NO 7623 >Circuit breaker closed
6106 BINARY INPUT 6 >CB OFF NO 7617 >Circuit breaker open
6107 BINARY INPUT 7 not marshalled NO 1 No function assigned to this input
6108 BINARY INPUT 8 not marshalled NO 1 No function assigned to this input
6109 BINARY INPUT 9 not marshalled NO 1 No function assigned to this input
6110 BINARY INPUT 10 >CB man.close NO 7618 >Circuit breaker manual close
NO: NO contact (active when energized)
NC: NC contact (active when not energized)
Table A-32 Marshalling Signal Relays of the bay unit 7SS525
Address 1st display line 2nd display line FNo. Comment
6201 SIGNAL RELAY 1 Bay o.of serv 7640 Bay is out of service
