Measured Value List - Central Unit
393
7SS52 V4 Manual
C53000-G1176-C182-3
A.13 Measured Value List - Central Unit
Abbreviations
Comments
$00, .., $03 are variables which are replaced automatically by
$00 Number of the bay unit
$01 Bay name
$02 Name of the switching element (e.g. isolator or circuit breaker)
$03 Name of the bus zone
Column Function: Checkzone I
d
, I
s
is not allocateable to the control center.
Column Information No. (Function Bus Zone): The bus zones1 to12 are assigned
to the Information numbers 100 to111. The basic-information number is given in brack-
ets.
Column Information No. (Function Bay Unit): The Information number corresponds
to the number of the bay unit assigned by you. The basic Information number is given
in brackets.
Column Position: The positions of the information in a block correspond to the posi-
tion given in the table. The basic-position number is given in brackets.
Column Configurable in Matrix: Control display and Default display not in 7SS52
V4.
FNo. Description Function IEC 60870-5-103 Configurable in
Matrix
Function type
Information No.
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
10401 CZ Idiff L1= (CZ Id1=) CZ Id, Is CFC
10402 CZ Idiff L2= (CZ Id2=) CZ Id, Is CFC
10403 CZ Idiff L3= (CZ Id3=) CZ Id, Is CFC
10404 CZ Istab L1= (CZ Is1=) CZ Id, Is CFC
10405 CZ Istab L2= (CZ Is2=) CZ Id, Is CFC
10406 CZ Istab L3= (CZ Is3=) CZ Id, Is CFC
176.1011 Current $01 in phase L1= ($01 IL1=) BU@ 132 (1) priv 9 (1) CFC
176.1012 Current $01 in phase L2= ($01 IL2=) BU@ 132 (1) priv 9 (2) CFC
176.1013 Current $01 in phase L3= ($01 IL3=) BU@ 132 (1) priv 9 (3) CFC
177.1301 $03 Idiff L1= ($03 Id1=) Protection
Zone
132 (100) priv 9 (1) CFC
177.1302 $03 Idiff L2= ($03 Id2=) Protection
Zone
132 (100) priv 9 (2) CFC
177.1303 $03 Idiff L3= ($03 Id3=) Protection
Zone
132 (100) priv 9 (3) CFC
177.1306 $03 Istab L1= ($03 Is1=) Protection
Zone
132 (100) priv 9 (4) CFC
177.1307 $03 Istab L2= ($03 Is2=) Protection
Zone
132 (100) priv 9 (5) CFC
177.1308 $03 Istab L3= ($03 Is3=) Protection
Zone
132 (100) priv 9 (6) CFC
