3357SS52 V4 Manual
C53000-G1176-C182-3
Appendix A
This appendix contains ordering information, general diagrams and connection dia-
grams, tabular listings of all settings and information of the distributed busbar and fail-
ure protection SIPROTEC 7SS52 V4 for the full scope of device functions.
A.1 Data for Selection and Ordering 336
A.2 Basis for Selection of the Stabilization Factor k 341
A.3 Connection Diagrams 342
A.4 Settings − Central Unit 348
A.5 Jumper Settings − Bay Unit 356
A.6 Protocol-Dependent Functions 364
A.7 Parameter Listing - Central Unit 365
A.8 Parameter Listing - Bay Unit 367
A.9 List of information - Central Unit 373
A.10 List of Information - Bay Unit 383
A.11 Group Alarms - Central Unit 389
A.12 Group Alarms - Bay Unit 392
A.13 Measured Value List - Central Unit 393
A.14 Measured Value List - Bay Unit 394
A.15 Marshalling - Central Unit 395
A.16 Marshalling - Bay Unit 7SS523 398
A.17 Marshalling - Bay Unit 7SS525 401
A.18 Navigation Tree - Central Unit 403
A.19 Navigation Tree of the Bay Unit 413
A.20 Abbreviations 414
A.21 References 415
