List of Information - Bay Unit
385
7SS52 V4 Manual
C53000-G1176-C182-3
1453 b.u. CBF act. Back-up breaker failure prot. is active OT 1 GI 166 153
1455 b.u. CBF flt. Back-up breaker fail. prot.: fault det. on OT 2 166 155
1471 b.u. CBF Trip Trip by back-up breaker failure prot. on OT 2 TA 166 171
1701 >O/C Ph on >Switch on O/C protection phase IOT
1702 >O/C Ph off >Switch off O/C protection phase IOT
1704 >O/C Ph block >Block overcurrent protection phases on/off IOT
1711 >O/C E on >Switch on overcurrent protection earth IOT
1712 >O/C E off >Switch off overcurrent protec. earth IOT
1714 >O/C E block >Block overcurrent protection earth on/off IOT
1721 >I>> block >Overcurrent protection:block stage I>> on/off IOT 1 GI 60 1
1722 >I> block >Overcurrent protection:block stage I> on/off IOT 1 GI 60 2
1723 >Ip block >Overcurrent protection:block stage Ip on/off IOT 1 GI 60 3
1724 >IE>> block >Overcurrent protec.: block stage IE>> on/off IOT 1 GI 60 4
1725 >IE> block >Overcurrent protection:block stage IE> on/off IOT 1 GI 60 5
1726 >IEp block >Overcurrent protection:block stage IEp on/off IOT 1 GI 60 6
1751 O/C Ph off Overcurrent prot. phase is switched off on/off OT 1 GI 60 21
1752 O/C Ph block Overcurrent prot. phase is blocked on/off OT
1753 O/C Ph active Overcurrent prot. phase is active OT 1 GI 60 23
1754 O/C I> off O/C protection phase is switched off I> on/off 1 GI 60 24
1755 O/C Ip off O/C protection phase is switched off Ip on/off 1 GI 60 25
1756 O/C E off O/C protection earth is switched off on/off IOT 1 GI 60 26
1757 O/C E block O/C protection earth is blocked OT
1758 O/C E active O/C protection earth is active OT 1 GI 60 28
1759 O/C IE> off O/C prot. earth is switched off IE> on/off 1 GI 60 29
1760 O/C IEp off O/C prot. earth is switched off IEp on/off 1 GI 60 30
1761 O/C Gen.Fault General fault detection O/C OT 2 CA GI p 84
1762 Fault L1 O/C fault detection phase L1 OT 2 CA GI p 64
1763 Fault L2 O/C fault detection phase L2 OT 2 CA GI p 65
1764 Fault L3 O/C fault detection phase L3 OT 2 CA GI p 66
1765 Fault E O/C fault detection earth OT 2 CA GI p 67
1771 Fault L1 O/C fault detection L1 only on 2 60 31
1772 Fault L1E O/C fault detection L1-E on 2 60 32
1773 Fault L2 O/C fault detection L2 only on 2 60 33
1774 Fault L2E O/C fault detection L2-E on 2 60 34
1775 Fault L12 O/C fault detection L1-L2 on 2 60 35
1776 Fault L12E O/C fault detection L1-L2-E on 2 60 36
1777 Fault L3 O/C fault detection L3 only on 2 60 37
1778 Fault L3E O/C fault detection L3-E on 2 60 38
1779 Fault L13 O/C fault detection L1-L3 on 2 60 39
1780 Fault L13E O/C fault detection L1-L3-E on 2 60 40
1781 Fault L23 O/C fault detection L2-L3 on 2 60 41
1782 Fault L23E O/C fault detection L2-L3-E on 2 60 42
FNo. Short Text Logical Function Log Buffers Configurable
in Matrix
IEC 60870-5-103
Event Log On/Off
Measured Value
Trip (Fault) Log On/Off
Binary Input I
Binary Output O
(LED, alarm relay)
Trip Relay T
Data Unit
Compatible Annunciation
General Interrogation
Annunc. for Fault Rec. Buffer
(Tagged)
Type (p: Corresponds to
parameter “Function type“)
Information Number
