Navigation Tree - Central Unit
407
7SS52 V4 Manual
C53000-G1176-C182-3
Main Menu Parameter Param.Group BB PROT. xx/yy
6103 STAB FAC CZ
>#.##
BB PROT. xx/yy
6104 Id> CZ
>#.##I/Ino
BF PROT.
6201 STAB FAC BF
>#.##
BU xx/yy
>BU01 -> xx
...
BUnn -> xx
BUxx xx/yy
xx12 Bay status
out of service
...
BUxx xx/yy
xx13 I> TRIP
#.##I/In
Supervision xx/yy
6305 Blocking Mode
>zone/phase
Table A-35 Navigation tree of the central unit
