Siemens SIPROTEC 7SS525 V3.3 User Manual

Appendix 410
7SS52 V4 Manual
C53000-G1176-C182-3
BU xx/yy
>BU01 -> xx
...
BUnn -> xx
BUxx
xx12 Bay status
>out of service
Main Menu Parameter
SETUP/EXTRAS xx/yy
>Date/Time -> x
Clock Setup -> x
Serial Ports -> x
Device # -> x
MLFB/Version -> x
Contrast -> x
Date/Time
Status: -- NS ER ST
>DD.MM.YYY hh:mm:ss
Diff. time:--------
CLOCK SETUP xx/yy
Source >T103
Error Time >100min
Offset >2min
Serial Ports xx/yy
>PC port -> x
System port -> x
Service port -> x
PC PORT xx/yy
Phys.Addr. >254
Baud rate>19200Baud
Parity >8E1
Gaps >#.##s
6th level for SYSTEM
PORT
IEC 60870-5-103xx/yy
Phys.Addr. >254
Baud rate>19200Baud
Parity >8E1
Gaps >#.##s
OFF-Sig. Light>off
SYSTEM PORT
>IEC 60870-5-103 ->x
SERVICE PORT xx/yy
Phys.Addr. >254
Baud rate>19200Baud
Parity >8E1
Gaps >#.##s
Table A-35 Navigation tree of the central unit
1st level 2nd level 3rd level 4th level 5th level
