Siemens SIPROTEC 7SS525 V3.3 User Manual

Matching the Control Voltage for the Binary Inputs and Inserting the Buffer Battery
37
7SS52 V4 Manual
C53000-G1176-C182-3
Table 3-4 Control voltage for the binary inputs on the EFE_10 (bay unit) in relation to the
fitted jumper
Control voltage setting
Name 24 V 60 V 110 V 220 V
BI 1 X37 X36 X35 -
BI 2 X40 X39 X38 -
BI 3 X43 X42 X41 -
BI 4 X46 X45 X44 -
BI 5 X49 X48 X47 -
BI 6 X52 X51 X50 -
BI 7 X55 X54 X53 -
BI 8 X58 X57 X56 -
BI 9 X79 X78 X77 -
BI 10 X76 X75 X74 -
