Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
510
Table 3-7 Jumper setting of the control voltages of the binary inputs BI1 to BI24 on the input/output
module C-I/O-1 or C-I/O-10 up to release 7SD5 .../EE with housing size
1
/
1
1)
Factory settings for devices with rated supply voltages of DC 24 V to 125 V
2)
Factory settings for devices with rated supply voltages of DC 110 V to 250 V and AC 115 V
3)
Factory settings for devices with rated supply voltages of DC 220 V to 250 V and AC 115 V
Table 3-8 Jumper settings of the module address of the input/output module C-I/O-1 or C-I/O-10 up to
release 7SD5 .../EE with housing size
1
/
1
Binary inputs Jumper Threshold 17
V
1)
Threshold 73
V
2)
Threshold
154 V
3)
Slot 33 left
side
Slot 19 right
side
Slot 19 left
side
BI1 BI9 BI17 X21/X22 L M H
BI2 BI10 BI18 X23/X24 L M H
BI3 BI11 BI19 X25/X26 L M H
BI4 BI12 BI20 X27/X28 L M H
BI5 BI13 BI21 X29/X30 L M H
BI6 BI14 BI22 X31/X32 L M H
BI7 BI15 BI23 X33/X34 L M H
BI8 BI16 BI24 X35/X36 L M H
Jumper Mounting location
Slot 19 left side Slot 19 right side
X71 H L
X72 L L
X73 H H
