Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
512
Table 3-9 Jumper setting of the control voltages of the binary inputs BI9 to BI16 on the input/output
module C-I/O-10 for release 7SD5 .../FF and higher with housing size
1
/
1
1)
Factory settings for devices with rated supply voltages of DC 24 V to 125 V
2)
Factory settings for devices with rated supply voltages of DC 110 V to 250 V and AC 115 V
3)
Factory settings for devices with rated supply voltages of DC 220 V to 250 V and AC 115 V
Table 3-10 Jumper setting of the module address of the input/output module C-I/O-10 for
release 7SD5 .../FF and higher with housing size
1
/
1
Binary inputs slot
19
Jumper Threshold 17 V
1)
Threshold 73 V
2)
Threshold 154 V
3)
B9 X21 L M H
BI10 X23 L M H
BI11 X25 L M H
BI12 X27 L M H
BI13 X29 L M H
BI14 X31 L M H
BI15 X33 L M H
BI16 X35 L M H
Jumper Mounting location
Slot 19 left side Slot 19 right side
X71 H L
X72 L L
X73 H H
