Siemens SIPROTEC User Manual

Appendix
A.8 Information List
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
739
7132 >BLOCK Backup OverCurrent
Ie>>> (>BLOCK O/CIe>>>)
Back-Up O/C SP on
off
**LEDBIBO64321Yes
7151 Backup O/C is switched OFF
(O/C OFF)
Back-Up O/C OUT on
off
**LEDBO64511Yes
7152 Backup O/C is BLOCKED (O/C
BLOCK)
Back-Up O/C OUT on
off
on off * LED BO 64 52 1 Yes
7153 Backup O/C is ACTIVE (O/C
ACTIVE)
Back-Up O/C OUT * * * LED BO 64 53 1 Yes
7161 Backup O/C PICKED UP (O/C
PICKUP)
Back-Up O/C OUT * off m LED BO 64 61 2 Yes
7162 Backup O/C PICKUP L1 (O/C
Pickup L1)
Back-Up O/C OUT * on * LED BO 64 62 2 Yes
7163 Backup O/C PICKUP L2 (O/C
Pickup L2)
Back-Up O/C OUT * on * LED BO 64 63 2 Yes
7164 Backup O/C PICKUP L3 (O/C
Pickup L3)
Back-Up O/C OUT * on * LED BO 64 64 2 Yes
7165 Backup O/C PICKUP EARTH
(O/C Pickup E)
Back-Up O/C OUT * on * LED BO 64 65 2 Yes
7171 Backup O/C Pickup - Only
EARTH (O/C PU only E)
Back-Up O/C OUT * on * LED BO 64 71 2 No
7172 Backup O/C Pickup - Only L1
(O/C PU 1p. L1)
Back-Up O/C OUT * on * LED BO 64 72 2 No
7173 Backup O/C Pickup L1E (O/C
Pickup L1E)
Back-Up O/C OUT * on * LED BO 64 73 2 No
7174 Backup O/C Pickup - Only L2
(O/C PU 1p. L2)
Back-Up O/C OUT * on * LED BO 64 74 2 No
7175 Backup O/C Pickup L2E (O/C
Pickup L2E)
Back-Up O/C OUT * on * LED BO 64 75 2 No
7176 Backup O/C Pickup L12 (O/C
Pickup L12)
Back-Up O/C OUT * on * LED BO 64 76 2 No
7177 Backup O/C Pickup L12E (O/C
Pickup L12E)
Back-Up O/C OUT * on * LED BO 64 77 2 No
7178 Backup O/C Pickup - Only L3
(O/C PU 1p. L3)
Back-Up O/C OUT * on * LED BO 64 78 2 No
7179 Backup O/C Pickup L3E (O/C
Pickup L3E)
Back-Up O/C OUT * on * LED BO 64 79 2 No
7180 Backup O/C Pickup L31 (O/C
Pickup L31)
Back-Up O/C OUT * on * LED BO 64 80 2 No
7181 Backup O/C Pickup L31E (O/C
Pickup L31E)
Back-Up O/C OUT * on * LED BO 64 81 2 No
7182 Backup O/C Pickup L23 (O/C
Pickup L23)
Back-Up O/C OUT * on * LED BO 64 82 2 No
7183 Backup O/C Pickup L23E (O/C
Pickup L23E)
Back-Up O/C OUT * on * LED BO 64 83 2 No
7184 Backup O/C Pickup L123 (O/C
Pickup L123)
Back-Up O/C OUT * on * LED BO 64 84 2 No
7185 Backup O/C Pickup L123E (O/C
PickupL123E)
Back-Up O/C OUT * on * LED BO 64 85 2 No
7191 Backup O/C Pickup I>> (O/C
PICKUP I>>)
Back-Up O/C OUT * on m LED BO 64 91 2 Yes
7192 Backup O/C Pickup I> (O/C
PICKUP I>)
Back-Up O/C OUT * on m LED BO 64 92 2 Yes
7193 Backup O/C Pickup Ip (O/C
PICKUP Ip)
Back-Up O/C OUT * on m LED BO 64 93 2 Yes
7201 O/C I-STUB Pickup (I-STUB
PICKUP)
Back-Up O/C OUT * on off m LED BO 64 101 2 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
