Siemens SIRIUS 3RN2 User Manual

Mounting
5.3 Mounting the devices on a standard mounting rail
SIRIUS 3RN2 thermistor motor protection relay
Manual, 10/2016, A5E34244868002A/RS-AA/001
29
5.3
Mounting the devices on a standard mounting rail
Requirements
● A horizontal 35-mm wide mounting rail in accordance with DIN EN 60715 has been
properly secured at the installation location.
Procedure
Step
Instructions
Figure
1 Place the back of the device
onto the upper edge of the
standard mounting rail.
2 Press the lower half of the
device against the DIN rail until
the device engages.
