SIRIUS 3RN2 thermistor motor protection relay
Manual, 10/2016, A5E34244868002A/RS-AA/001
33
Connection
6
6.1 Terminal assignment
Location of the connections
The inside faces of the terminal covers are labeled with the designations of the relevant
terminals. The position of the label corresponds to the position of the respective terminal.
NOTICE
Risk of property damage
When using the terminals, you must observe the correct position of the terminals (see
inside of cover).
Upper terminal cover Lower terminal cover
