Connection
6.7 Disconnect the spring-loaded terminal (push-in)
SIRIUS 3RN2 thermistor motor protection relay
44 Manual, 10/2016, A5E34244868002A/RS-AA/001
6.7
Disconnect the spring-loaded terminal (push-in)
WARNING
Hazardous Voltage
Can Cause Death, Serious Injury, or Property Damage.
Before starting work, therefore, disconnect the system and devices from the power supply.
Requirements
● DIN 5264 screwdriver with size 0.5 x 3 mm
(article number of the screwdriver: 3RA2908-1A)
Procedure
Step
Instructions
Figure
1 Insert the screwdriver into
the rectangular opening of
the spring-loaded terminal
until it engages.
2 Remove the cable from the
oval opening.
3 Remove the screwdriver.
