Mounting
5.4 Disassembling devices from a standard mounting rail
SIRIUS 3RN2 thermistor motor protection relay
30 Manual, 10/2016, A5E34244868002A/RS-AA/001
5.4
Disassembling devices from a standard mounting rail
WARNING
Hazardous Voltage
Can Cause Death, Serious Injury, or Damage to Property.
Before starting work, therefore, disconnect the system and devices from the power supply.
Requirements
● The terminals have been removed or disconnected.
Procedure
Step
Instructions
Figure
1 Press the device
downwards.
2 Pull the lower half of the
device away from the
standard mounting rail.
3 Lift the device from the
upper edge of the DIN rail.
