Connection
6.1 Terminal assignment
SIRIUS 3RN2 thermistor motor protection relay
34 Manual, 10/2016, A5E34244868002A/RS-AA/001
Note
Terminal cover/article number
The complete article number is engraved on each terminal cover (upper and lower) via laser.
The article numbers permit correct assignment of the terminal cover to the unit if you have
removed the terminal cover. If a terminal cover is lost or damaged, you can simply print out
the
figures of the following table in their original size, and glue them into a neutral
replacement terminal cover. You can obtain replacement terminal covers from Siemens
Support.
You can use the terminal labels for modules with screw
-type terminals and spring-loaded
Parts of the article numbers that are not necessary for assignment to the terminal functions
have been replaced by periods as placeholders.
