Connection
6.1 Terminal assignment
SIRIUS 3RN2 thermistor motor protection relay
Manual, 10/2016, A5E34244868002A/RS-AA/001
35
The following tables shows the terminal assignments in the terminal covers of the SIRIUS
thermistor motor protection relays:
Module version
Inscription of the terminal cover
Upper
terminal cover
Lower
terminal cover
Terminal
assignment
on the device
Overall width 17.5 mm
Compact units
3RN2000-.AA30
3RN2000-.AW30
Standard units
3RN2010-.CA30
3RN2010-.CW30
