Connection
6.1 Terminal assignment
SIRIUS 3RN2 thermistor motor protection relay
36 Manual, 10/2016, A5E34244868002A/RS-AA/001
Module version
Inscription of the terminal cover
Upper
terminal cover
Lower
terminal cover
Terminal
assignment
on the device
Overall width 22.5 mm
Standard units
3RN2010-.BA30
3RN2010-.BW30
3RN2011-.BA30
3RN2011-.BW30
3RN2012-.BA30
3RN2013-.BA30
3RN2012-.BW3.
3RN2013-..W30
