Mounting
7.3 Assembly and disassembly with different mounting systems
SIRIUS - SIRIUS 3RA load feeders
Manual, 09/2016, A5E03656507520A/RS-AB/003
81
Place the link module on the bottom of the motor starter protector. Insert the hooks into the
hooking openings on the motor starter protector. Insert the connectors into the corresponding
main conductor terminals.
Screw the main conductor terminals tight.
Unscrew the main conductor terminals of the contactor fully.
Insert the motor starter protector with mounted link module and hooks into the hooking
openings on the contactor. Insert the connectors on the link module into the corresponding
main conductor terminals at the same time. A swivel action is required for this.
Screw the main conductor terminals tight on the contactor.
Place the feeder on the DIN rail adapter.
Screw the feeder to the DIN rail adapter. The feeder sits tight on the adapter.
Tightening torque: 1.2 ... 1.5 Nm
Note
For vibration and shock requirements, the washer must be replaced with a wedge lock
washer (DIN 50021
-SS 4.4 x 9.0 x 1.7).
Disassembling the feeder from the DIN rail adapter
To disassemble the feeder, unscrew the screws and pull the feeder down to remove it.
