Process value Decimal code From DR Format
G/N weight (after low-pass filter 1) 4 30 REAL
G/N weight_x10 5 30 REAL
Unfiltered digit value 9 31 DINT
filtered digit value (after low-pass fil‐
ter 1)
10 31 DINT
Refresh counter 12 30 UINT
Async. Error bits (32-bit):
bits 0..15: operator error
Bits 16..31: technology error
15 32 DINT
Gross process (after low-pass filter 2) 7 - REAL
Net process (after low-pass filter 2) 8 - REAL
Filtered digit value (after low-pass fil‐
ter 2)
11 - DINT
8.13 DR 15 manual tare specification
Data recorder DR 15 is used for an external specification of a tare weight.
Procedure
● Enter the tare weight
● Transfer the data record to the scale
● Enable the tare weight using command 1013
Table 8-10 Assignment of data record 15
Variable Note Type L Rw Default Min. Max.
Data record
number
Contains no.
of data record
UINT 2 r 15 - -
Length Data record
length infor‐
mation
UINT 2 r 16 - -
Application Information
about which
application
the DR be‐
longs to
UINT 2 r 201 - -
Version iden‐
tifier
Information
on the cur‐
rent data re‐
cord version
UINT 2 r 1 1 65635
Specification
of tare
weight
(Page 84)
Tare specifi‐
cation memo‐
ry (manual
tare value)
REAL 4 rw 0 0 Depends on
specification
in DR 3
Reserve Reserve REAL 4 rw 0 0 -
Scale parameters and functions
8.13 DR 15 manual tare specification
SIWAREX WP321
Operating Instructions, 08/2019, A5E33715669A-AD 83
