8.15.2 Filtered digit value
The filtered digit value is the internal measured value immediately after filtering.
8.15.3 Refresh counter for process values
Measured values are calculated every 10 ms in the SIWAREX module. A counter is
incremented by 1 each time. Once the counter reaches the value 65536, it starts again from
zero. The counter can be used as a time stamp for data record DR 31.
8.16 DR 32 Message display
Data record 32 indicates all pending message bits. The bit "Error status changed" is present in
the status bits of the DR30. If this bit is set, the message area of the DR32 has been changed.
The DR32 indicates which message has been newly added or deleted. The data record is
automatically read by the SIMATIC FB in the event of an error. Following successful reading,
the status bit is reset in DR30.
Table 8-13 Assignment of data record 32
Variable Note Type L Rw De‐
fault
Min. Max.
Data record
number
Contains no. of data record UINT 2 r 32 - -
Length Data record length information UINT 2 r 26 - -
Application Information about which application the
data record belongs to
UINT 2 r 101 - -
Version identi‐
fier
Information on the current data record
version
UINT 2 r 1 1 65635
1000 Operator error BIT r 0 0 1
Reserve - BIT r 0 0 1
1104 Undervoltage BIT r 0 0 1
Reserve - BIT r 0 0 1
1105 Overload BIT r 0 0 1
1106 Underload BIT r 0 0 1
1002 RAM error BIT r 0 0 1
1102 ADC error BIT r 0 0 1
1005 Hardware interrupt lost BIT r 0 0 1
1003 Checksum error data BIT r 0 0 1
Reserve - BIT r 0 0 1
1004 Checksum error program BIT r 0 0 1
Reserve - BIT r 0 0 1
1001 RESET / restart following error (watch‐
dog)
BIT r 0 0 1
1110 No communication with SIWAREX DB BIT r 0 0 1
Scale parameters and functions
8.16 DR 32 Message display
SIWAREX WP321
88 Operating Instructions, 08/2019, A5E33715669A-AD
