Variable Note Data type Length
(bytes)
Rw Default Min. Max.
Load cell manufacturer
[LOAD_CELL_MANUFAC‐
TURER]
Load cell manufacturer CHAR[24] 24 r/w „ „ - -
Load cell order number
[LOAD_CELL_ORDER_NUM‐
BER]
Load cell order number CHAR[24] 24 r/w „ „ - -
Load cell input 1: Location des‐
ignation of sensor
[LOAD_CELL_INPUT_1_LO‐
CATION_TAG]
Location designation of sensor CHAR[24] 24 r/w „ „ - -
Load cell input 2: Location des‐
ignation of sensor
CHAR[24] 24 r/w „ „ - -
Load cell input 3: Location des‐
ignation of sensor
CHAR[24] 24 r/w „ „ - -
Load cell input 4: Location des‐
ignation of sensor
CHAR[24] 24 r/w „ „ - -
Channel active
[LOAD_CELL_ENABLE]
Bit 0: Load cell input 1 [IN‐
PUT_1]
Bit 1: Load cell input 2 [IN‐
PUT_2]
Bit 2: Load cell input 3 [IN‐
PUT_3]
Bit 3: Load cell input 4 [IN‐
PUT_4]
USHORT 2 r/w 15 0 15
Sensor type
[SENSOR_TYPE]
0: 4-wire sensor
1: 6-wire sensor
USHORT 2 r/w 0 0 1
Total capacity of all load cells
[NOMINAL_LOAD]
Total capacity of all load cells FLOAT 4 r/w 1000 tbd tbd
8.19 DR 80 SIWAREX DB process status
In data record DR 81, monitor the current statuses and process values in the scales with the
help of the SIWAREX DB. To optimize the parameters, monitor selected data when
commissioning the scales.
It is not always necessary to cyclically read data record DR 80. Messages and status bits are
automatically read out by the function block when a change occurs.
Table 8-16 Assignment of data record DR 80
Variable Note Type Length
(bytes)
Rw Default Min. Max.
Data record number
[DR_NO]
Contains no. of data record USHORT 2 R 80 - -
Length [DR_LEN] Data record length infor‐
mation
USHORT 2 R 76 - -
Scale parameters and functions
8.19 DR 80 SIWAREX DB process status
SIWAREX WP321
92 Operating Instructions, 08/2019, A5E33715669A-AD
