Variable Note Type Length
(bytes)
Rw Default Min. Max.
Application [APPL_ID] Information on which appli‐
cation the data record be‐
longs to
USHORT 2 R 101 - -
Version identifier [DR_VER‐
SION]
Information on the current
data record version
USHORT 2 r 1 1 65635
Refresh counter
[REFRESH_COUNTER]
Cycle counter of the SI‐
WAREX DB incremented
by 1 if process values
have been changed.
USHORT 2 r 0 0 0xFFFF
Device status
[MODULE_ERROR_IN‐
FORMATION]
Bit 0: QI flag
Bit 1: Load cell input faulty
Bit 2: Checksum error
Bit 3: Checksum error (da‐
ta)
Bit 4: Watchdog error
Bit 5: ADC error
Bit 6: Temperature warn‐
ing
Bit 7: Firmware update er‐
ror
USHORT 2 r 0 - -
Load cell input 1: Status
[LOAD_CELL_INPUT_1_DI‐
AGNOSTIC_INFORMA‐
TION]
Bit 0: QI flag
Bit 1: Underload
Bit 2: Overload
Bit 3: SEN error
Bit 4: Impedance error
Bit 5: EXC short circuit
Bit 6: Power supply failure
USHORT 2 r 0 - -
Load cell input 1: filtered dig‐
it value
[LOAD_CELL_IN‐
PUT_1_DIGITS_FILTERED]
Filtered digit value of AD
converter from SIWAR‐
EX DB to dig. filter 1
LONG 4 r 0x7FFF
FFFF
0x8000
0000
0x7FFF
FFFE
Load cell input 1: Load (%)
[LOAD_CELL_IN‐
PUT_1_PERCENT‐
AGE_LOAD]
Current percentual load of
the load cell in relation to
the rated load of the load
cell
FLOAT 4 r 0 -200 200
Load cell input 1: Signal volt‐
age SIG (mV)
[LOAD_CELL_IN‐
PUT_1_LOAD_CELL_SIG‐
NAL]
Currently measured load
cell signal
Float 4 r 0 -200 200
Load cell input 2: Status Bit 0: QI flag
Bit 1: Underload
Bit 2: Overload
Bit 3: SEN error
Bit 4: Impedance error
Bit 5: EXC short circuit
Bit 6: Power supply failure
USHORT 2 r 0 - -
Scale parameters and functions
8.19 DR 80 SIWAREX DB process status
SIWAREX WP321
Operating Instructions, 08/2019, A5E33715669A-AD 93
