Siemens SIWAREX WP321 User Manual

Variable Note Type Length
(bytes)
Rw Default Min. Max.
Load cell input 2: Filtered
digit value
Filtered digit value of AD
converter from SIWAR‐
EX DB to dig. filter 1
LONG 4 r 0x7FFF
FFFF
0x8000
0000
0x7FFF
FFFE
Load cell input 2: Load (%) Current percentual load of
the load cell in relation to
the rated load of the load
cell
FLOAT 4 r 0 -200 200
Load cell input 2: Signal volt‐
age SIG (mV)
Currently measured load
cell signal
Float 4 r 0 -200 200
Load cell input 3: Status Bit 0: QI flag
Bit 1: Underload
Bit 2: Overload
Bit 3: SEN error
Bit 4: Impedance error
Bit 5: EXC short circuit
Bit 6: Power supply failure
USHORT 2 r 0 - -
Load cell input 3: filtered dig‐
it value
[LOAD_CELL_IN‐
PUT_3_DIGITS_FILTERED]
Filtered digit value of AD
converter from SIWAR‐
EX DB to dig. filter 1
LONG 4 r 0x7FFF
FFFF
0x8000
0000
0x7FFF
FFFE
Load cell input 3: Load (%) Current percentual load of
the load cell in relation to
the rated load of the load
cell
FLOAT 4 r 0 -200 200
Load cell input 3: Signal volt‐
age SIG (mV)
Currently measured load
cell signal
Float 4 r 0 -200 200
Load cell input 4: Status Bit 0: QI flag
Bit 1: Underload
Bit 2: Overload
Bit 3: SEN error
Bit 4: Impedance error
Bit 5: EXC short circuit
Bit 6: Power supply failure
USHORT 2 r 0 - -
Load cell input 4: Filtered
digit value
Filtered digit value of AD
converter from SIWAR‐
EX DB to dig. filter 1
LONG 4 r 0x7FFF
FFFF
0x8000
0000
0x7FFF
FFFE
Load cell input 4: Load (%) Current percentual load of
the load cell in relation to
the rated load of the load
cell
FLOAT 4 r 0 -200 200
Load cell input 4: Signal volt‐
age SIG (mV)
Currently measured load
cell signal
Float 4 r 0 -200 200
Scale parameters and functions
8.19 DR 80 SIWAREX DB process status
SIWAREX WP321
94 Operating Instructions, 08/2019, A5E33715669A-AD
