8.14.7 Refresh counter for process values
Measured values are calculated every 10 ms in the SIWAREX module. A counter is
incremented by 1 each time. Once the counter reaches the value 65536, it starts again from
zero. The counter can be used as a time stamp for data record DR 30.
8.15 DR 31 advanced current process values
Current states and process values in the scales can be monitored using advanced process
values and process values (DR 30). This data is not required for standard operation of the
scales.
Monitoring selected data during trial operation is extremely useful as it helps you to optimize
parameters.
Procedure
● Read data record DR 31
● Display/analyze the required tags
Table 8-12 Assignment of data record 31
Variable Note Type L Rw Default Min. Max.
Data record
number
Contains no. of data record UINT 2 r 31 - -
Length Data record length information UINT 2 r 24 - -
Application Information about which applica‐
tion the data record belongs to
UINT 2 r 201 - -
Version iden‐
tifier
Information on the current data re‐
cord version
UINT 2 r 1 1 65635
Unfiltered dig‐
it value
(Page 87)
Unfiltered digit value of AD con‐
verters / digital load cells
DINT 4 r 0 - -
Filtered digit
value
(Page 88)
Filtered digit value of AD convert‐
ers or digital load cells after dig. fil‐
ter 1
DINT 4 r 0 - -
Reserve 1 INT 2 r 0 -100 100
Refresh
counter for
process val‐
ues
(Page 88)
Refresh counter incremented by 1
if weight values have been
changed
UINT 2 r 0 - -
Reserve 2 REAL 4 r 0 - -
8.15.1 Unfiltered digit value
The unfiltered digit value is the internal measured value immediately before filtering.
Scale parameters and functions
8.15 DR 31 advanced current process values
SIWAREX WP321
Operating Instructions, 08/2019, A5E33715669A-AD 87
