24 SONOLINE G20 System Delivery Procedure
SONOLINE G20 US06-101.812.01.02.02 Siemens
10.04 sd
Page 24 of 26
Medical Solutions USA, Inc.
4. Press the Frame/Field/Enter button to select each hidden feature in succession, item
E. Then rotate the Jog Dial to change the values of each feature, item F. The following
is a list of the hidden features and their corresponding settings:
5. Press Stop to exit the hidden menu.
6. Press and hold the Menu button (item G) for three seconds to access Menu 1
(101:xx), Menu 2 (201:xx), and Menu 3 (301:xx).
Hidden Feature Setting
Picture Control -1
Switching Point (SP) 45
Position Up/Down (Ud) 0
Position L/R (Lr) 0
Chroma Amplitude (CA) -3
Hue (CP) 1
Color Delay (CD) 3
Brightness Control 0
Contrast Control 0
Black Display AL
The Black Display function has three
options AL, ON, and OFF.
• AL - During playback, unrecorded sec-
tions of tape will be displayed in black.
• ON - During playback, unrecorded sec-
tions of tape will be displayed as blank
video.
• OFF - Noise displays in all modes.
