Siemens Sonoline G20 User Manual

Siemens US06-101.812.01.02.02 SONOLINE G20
10.04 sd
SONOLINE G20 System Delivery Procedure 7
Page 7 of 26
Medical Solutions USA, Inc.
4. Release and remove the three Corro clips, located on the front of the shipping contain-
er.
- To release the clip, squeeze the two vertical bars together and then pull the top of the
bars down and away from the clip.
- To remove the clip, pull the clip away from the cardboard box.
Fig. 1: Corro Clip Removal
Pos. A Squeeze together to release lock
Pos. B Pull away from the shipping container
5. Unpack the shipping crate.
- Remove the accessory box.
- Remove the cardboard box from the G20 system.
- Remove and retain the screws that secure the two roll-out ramps to the cardboard
base; remove the two ramps.
Fig. 2: Shipping Base
Pos. A Roll-out ramp
Pos. B Ramp screws
Pos. C Cardboard Base
