5 – 1

5 Installation

DANGER

Hazardous voltage.

Will cause death, serious personal injury, or equipment damage.

Turn off and lock out all power supplying this device before working on this device.

DANGER

Heavy Equipment.

Improper lifting will cause death, serious personal injury, or equipment/property damage.

Never lift a circuit breaker, fuse carriage, or cradle above personnel. Follow instructions for use of lifting bar assembly.

Use OSHA/NIOSH approved crane equipment and personal protection equipment for lifting/moving the circuit breakers

and cradles.

WARNING

High speed moving parts.

Can cause serious personal injury.

Discharge the closing spring before inspection and before carrying out any work on the circuit breaker.
