Siemens UL 1066 - Breaker Secondary Disconnect

5 – 11
5.4.1 Breaker Secondary Disconnect
Arrangement
(1) Arc chute
(2) Secondary disconnect block
Field installation
(1) Dummy block
(2) Secondary disconnect block
(3) Secondary disconnect adapter block for high arc chutes.
X5
X6X8X9
(1)
(2)
COM15
COM16
0173-06
(1)
(2)
1
2
3
4
0173-09
(3)
5
6
0,7 Nm
PH 1
6 lb-in
TX 8
or
