18 – 11

Installation

Depending on spatial conditions in the switchgear assembly, it may be necessary to wire the TOC prior to installation.

Then:

- Insert the circuit breaker into the cradle and rack it into the connected position  (page 6-1)

Catalog numbers

TOC Version Catalog No.

1 CONNECT, 1 TEST, 1 DISCONNECT

WLGSGSW111

3 CONNECT, 2 TEST, 1 DISCONNECT

WLGSGSW321

6 CONNECT

WLGSGSW6
