Install fuse
(1) M12 socket head cap screw
(2) Belleville washer
(3) Ring terminal
(4) Threaded plate
(5) 2 x self-tapping collar screws M4
6
7
8
9
10
11
12
13
PH 1
Size
10
4
1
2
3
4
5
6
PH 1
3,2 Nm
9
(5)
28 lb-in
7
8
(1)
(2)
(3)
(4)
Size
10
70 Nm
50 ft-lb
11
10
11
Size
5
8 Nm
71 lb-in
