Operation steps ：
● Channel 1“Volt/div”and vertical “POSITION” set up the horizontal scale
and position.
● Channel 2“Volt/div”and vertical “POSITION” set up the horizontal scale
and position.
● Turn the “S/div” knob to adjust the sampling rate
● The following functions are forbidden at XY display form:
● Benchmark wave form and wave mathematic
● Cursor
● Auto（resets display format to YT）
● Trigger Control
● Horizontal Position Knob
● Vector Display Type
● Scan Display
Note：When the display Type is set to Vectors, the oscilloscope
connects the sample points by using digital interpolation.
Interpolation mode contain linearity interpolation and sin(x)/x
interpolation. Sin(x)/x interpolation is suitable for real time mode.
It is effective at 250ns/div or at faster time base in real time mode.
