adjust grid brightness.
4. Set up display format
1) Press the “Next Page” option button to enter second display menu.
2) Press the “Format” option button to select “YT” or “XY”.
5. Set up Screen
Press the “Screen” option button to select “Normal” or “Inverted” to
set the screen display color.
6. Set up Grid
Press the “Grid” option button to select “
”,
“
”or“ ”to set the screen whether display grid or not.
7. Set up Menu Display
Press the “Menu Display” option button to select “2 sec”, “5sec”,
“10sec”, “20sec” or “Infinite” to set menu display time on screen.
8. Set Skin
Press the “skin” option button or turn the “Universal” knob to select
“Classical”, “Modern”, “Traditional” or “Succinct”.
2.10.1 X-Y Format
Use the XY format to analyze phase differences, such as those represented by
Lissajous patterns. The format plots the voltage on channel 1 against the voltage on
channel 2, where channel 1 is the horizontal axis and channel 2 is the vertical axis.
The oscilloscope uses the untriggered Sample acquisition mode and displays data as
dots.
XY mode has a breakthrough that trad oscilloscopes restrict sampling rate at
1MSa/s，500MSa/s rate-time series support 25KSa/s～100MSa/s (1-2.5-5 sequence)
adjusted. 1GSa/s rate-time series support 25KSa/s～100MSa/s (1-2.5-5 sequence)
adjusted;2GSa/s rate-time series support 10KSa/s ～ 1GSa/s (1-2.5-5 sequence)
adjusted
Note：The oscilloscope can capture a waveform in normal YT mode
at any sampling rate. You can view the same waveform in XY mode.
To do so, stop the acquisition and change the display format to XY.
