Instructions, use and maintenance manual Pag. 35/49
SAU 160-200
14.6. Special maintenance
For operations that are not specifically mentioned in the manual, you must refer to personnel
authorised by the seller. To replace the motor and electronic boards or following a machine fall,
contact our customer service (for on-site assistance or an in-factory inspection).
replacement of mobile guard micro
: remove the screws holding the upper casing
together with the structure, place the upper casing onto a flat surface and make sure that the sheath
containing the wires is not taut, loosen the screws (1) and remove the micro-switch square.
Check the micro-switch, change it in case of failure and/or breakage. Put the micro-switch back in the
square and tighten the ring nut (1).
Check the cam controlling the micro-switch (2), checking the grub screws draw.
