Instructions, use and maintenance manual Pag. 43/49
SAU 160-200
Pos. Q.ty Description Drawing
1 1 SAU-B SCREW COVERING CASING 02170112
1 1 SAU-T SCREW COVERING CASING 02170113
2 1 UCFC SUPPORT 13006202
3 1 WORM SCREW CARRIER SHAFT ASSEMBLY 86170045-1
4 6 BUSHING KU 50x55x50 15005014
5 6 SLIDING WHEEL 84170050
6 1 SAU-B SCREW 01170094
6 1 SAU-T SCREW 01170033
7 1 LABYRINTH COVER 80170038-1
8 1 6210 BEARING 13000321
9 1 SCREW BUSHING TUBE 01170034
10 1 NILOS RING 14000715
11 1 T100 4P 2.2KW 230-400V/3/50HZ 11001301
12 1 T100 MOTOR SEAT 86170026-1
13 1 T100 MOTOR PULLEY 01170028
14 1 CONDUIT PULLEY 01168015
15 1 SAU-B GUIDE UPRIGHT 86170092
15 1 SAU-T GUIDE UPRIGHT 86170023-1
15 2 SAU LOWER LEVER 86170051
15 1 RIGHT UPPER LEVER ASSEMBLY 86170055
15 1 LEFT UPPER LEVER ASSEMBLY 86170056
16 1 CONTROL PANEL 85123145-1
16 1 EMERGENCY BUTTON 25009050
16 2 DOUBLE TIMER 25007022
16 1 MASTER SWITCH 25003013
17 1 BASE ASSEMBLY 8617006-1
18 2 INDUCTIVE SENSOR 25001371
19 1 DUCT PULLEY HUB 01170029
20 1 POLY-V BELT 12003959
21 1 LOCK-NUT 85021135-1
22 1 32215 BEARING 13000514
23 1 SEAL RING 19000035
24 1 WORM SCREW PROTECTION 86170049-1
25 1 SAFETY WORM SCREW 01170048
26 1 LIFTING WORM SCREW 01170047
