Instructions, use and maintenance manual Pag. 44/49
SAU 160-200
Pos. Q.ty Description Drawing
27 1 CONNECTION ASSEMBLY 86197110-2
28 1 RIGHT CONTRAST WHEEL COVER 02197048
28 1 LEFT CONTRAST WHEEL COVER 02197049
29 2 CONTRAST PIN 01193044-1
30 4 6204 BEARING 13000015
31 2 POLYURETHANE WHEEL 17001501
32 1 UPPER CASING 03197045-1
33 1 SAU 160 BOWL 04197128
33 1 SAU 200 BOWL 04197127
34 1 FIXED PASTA COVER SAU 160 01197140-2
34 1 FIXED PASTA COVER SAU 200 01197133-1
35 1 PIZZATO MICRO-SWITCH 25001308
36 1 MICRO-SWITCH CONTROL CAM 01078048
37 1 PROTECTION PROFILE TUBE 87197053
38 1 BOWL COVERING SHEET METAL ONLY 160 made of ABS 01196050-1
39 3 COLLAR TORQUE 14002512
40 1 MOBILE PASTA COVER SAU 160 01197141-3
40 1 MOBILE PASTA COVER SAU 200 01197132-1
41 2 MOBILE PROTECTION PIN 85193059-3
42 1 BASE FRONT CLOSURE 86197022-1
43 2 FOOT BLOCK 85193020-1
43 2 FOOT 14002823
44 1 BASE 86197021-4
45 1 6209 BEARING 13000020
46 1 RETURN DRIVE PULLEY 01197040
47 1 SPIRAL PULLEY 01197043-1
48 6 SPA 1657 BELT 12003106
49 5 SPZX 1112 BELT 12003302
50 1 MOTOR PULLEY 01197038
51 1 6310 BEARING 13000031
52 1 RETURN SHAFT 01197041-2
53 1 SPIRAL SHAFT 85169043-4
54 1 SPIRAL MOTOR PLATE 86197116-1
55 1 T132 2/4P 9.2/7.4KW 400V/3/50HZ 11001851
56 1 SPIRAL 01169048-1
