Instructions, use and maintenance manual Pag. 45/49
SAU 160-200
Pos. Q.ty Description Drawing
57 1 CONTRAST ROD ASSEMBLY 01197067
58 1 SPIRAL LABYRINTH COVER 01169044-1
59 2 SEAL RING 19000060
60 2 32215 BEARING 13000519
61 1 SPIRAL BUSH 01169006-1
62 2 32213 BEARING 13000509
63 1 NILOS RING 14000740
64 2 LOCK-NUT 01169064-1
65 1 RETURN TENSIONING PLATE 02197042-1
66 1 RETURN DUCT PULLEY 01197039
67 1 PULLEY REINFORCEMENT RING 01197123-1
68 1 SHRINK DISC 14000501
69 1 BOWL SHAFT 01197060-3
70 1 BOWL BUSHING 85197056-3
71 1 BOWL CROWN HUB 01197063-1
72 1 T80 4P 0.75KW 230-400V/3/50HZ 11000707
73 1 BOWL MOTOR PLATE 86196040
74 1 TENSIONER 23010151
75 1 BOWL RETURN SHAFT 01197117
76 2 6208 BEARING 13000019
77 1 BOWL MOTOR PULLEY 01196035-1
78 1 POLY-V BELT 12003976
79 1 BOWL RETURN PULLEY 01197106-3
80 1 SAU 160 CHAIN 12000350
80 1 SAU 200 CHAIN 12000351
81 1 GEAR Z8 84197029-4
82 1 Z71 BOWL CROWN 01197064-3
83 1 BELT TIGHTENER CROWN 01197037-1
84 1 6206 BEARING 13000017
85 1 SHAFT SUPPORT HALF-RING 01196042-2
86 1 BELT TIGHTENER SHAFT 85197036-3
87 1 BELT TIGHTENER TENSIONING PLATE 02196031-1
