35
MODULAR CHUTE SYSTEM
W = Package Width
H = Package Height
INDIVIDUAL CHUTE SIZES BY ASSEMBLY PART NUMBER
HIGH FRAME, WITH SHORT VIBRATOR
18"W 24"W 30"W 36"W 48"W 60"W 72"W
18"H 260200 260201 260202 260203 260204 260205 260206
24"H 260207 260208 260209 260210 260211 260212 260213
LOW FRAME, WITH STANDARD VIBRATOR
30"H 260287 260292 260214 260215 260301 260304 260307
36"H 260288 260293 260216 260217 260218 260219 260308
48"H 260289 260294 260220 260221 260222 260223 260309
60"H 260290 260295 260297 260299 260302 260305 260310
72"H 260291 260296 260298 260300 260303 260306 260311
For Parts & Service 1-877-862-6699
